Attribute：
Product properties:
1. Electrical properties
LC：≤0.10µA/cm2
Formation condition：
Formation liquid: 0.1%H3PO4
Formation temperature: 90±2
Density of the frmation Current: 5mA/cm2
Formation voltage/time: 225V/30min
Parameter：
Spec. diameter tolerance allowed
| Specification mm | Diameter tolerance allowed mm |
| 0.10mm~0.15mm | ±0.005 |
| >0.15mm~0.30mm | ±0.006 |
| >0.30mm | ±0.007 |
Mechanical properties
| Product condition | Tensile strength Mpa | Elongation % |
| Annealled | 300~600 | 10~30 |
| Half annealed | >600~1000 | <5 |
| Unannealled | >1000 | <5 |
Applications：
Product properties:
1. Electrical properties
LC：≤0.10µA/cm2
Formation condition：
Formation liquid: 0.1%H3PO4
Formation temperature: 90±2
Density of the frmation Current: 5mA/cm2
Formation voltage/time: 225V/30min
