Attribute：
A metallic element, titanium is recognized for its high strength-to-weight ratio. It is a strong metal with low density that is quite ductile (especially in an oxygen-free environment),lustrous, and metallic-white in color. The relatively high melting point (more than 1,650 °C or 3,000 °F) makes it useful as a refractory metal. It is paramagnetic and has fairly low electrical and thermal conductivity.
Parameter：
Grade |
Manufacturing |
State |
Diameter (mm) |
Standard |
|
Gr1 Gr2
Gr2 Gr3 |
|
|
|
ASTM B348 |
| Grade | Size | State | Standard |
| Gr5 | Φ2~Φ4×L | polishing | ASTM F136 |
| Gr5 | Φ4~Φ8×L | polishing | |
| Gr5 | Φ8~Φ10×L | polishing | |
| Gr5 | Φ10~Φ16×L | polishing | |
| Gr5 | Φ16~Φ30×L | polishing | |
| Gr5 | Φ8~Φ10×L | Rolling | |
| Gr5 | >Φ10~Φ16×L | Rolling | |
| Gr5 | >Φ16~Φ30×L | Rolling | |
| Gr5 | Φ30~Φ60×L | Rolling | |
| Gr5 | Φ20~Φ60×L | Rolling |
Applications：
1) Orthopedic implants : artificial joints, metal plate, orthopedic nails, metal orthopedic use rods, intramedullary nail，bone needles, spinal fixation devices.
2) Heart medicine implants:artificial heart valves, cardiac pacemakers, cardiac catheters and stents within blood vessels.
3) Ophthalmic implants: artificial crystal.
4) Dental Implants: Dental Implant, traction nails,nail plant root canal, internal fixation devices ect.
5) Filling Materials : breast fillings intraocular filling materials, filling materials in orthopedics.
